Kearns & Richards 5.11" 3-Axis CNC Table Type Horizontal Boring Mill with Programmable Facing Head
Sold
Kearns & Richards 5.11" 3-Axis CNC Table Type Horizontal Boring Mill with Programmable Facing Head
Location:Mississauga, Canada
Description
FANUC Series 3TI-Model B 5-Axis CNC Control | Coolant | Chip Conveyor | Outboard Supports | 600V/3PH/50-60HZ | Re-manufactured & Retrofit 2017 | Pictured Rotary Table NOT Included--Can Furnish On Request
Specifications
| Manufacturer | Kearns & Richards |
| Model | KHT130L |
| Year | 2017 |
| Condition | Used |
| Serial Number | 8000 |
| Stock Number | 22279 |
| Spindal Diameter | 5.11" |
| Spindle Taper | #50 |
| Spindle Speeds | to 1,120 RPM |
| Table Size | 102" x 49.25" |
| X-Axis Travel (Table Cross) | 118" |
| Y-Axis Travel (Vertical) | 59" |
| Z-Axis Travel (Spindle Quill) | 31" |
| W-Axis Travel (Table Longitudinal) | 61" |
| U-Axis Travel (Facing Head Slide) | 7.60" |
